9
1. Specifications
1.3 Outline Drawing
System weight: 48.4 kg (plasma display (PDP-504CMX) 41.0 kg plus handwriting device 7.4 kg)
Materials: Front panel (frame) ............................ Aluminum
Corner sections ................................. Resin
Base shield, corner reinforcement .... Metal plate
Finish: Front panel (frame) ............................ Painting (Pioneer original color)
Base shield, corner reinforcement .... Plating
Unit : mm
758
120 220
1258
115
74
82
92
56
58
Plasma display indicator
Remote control
sensor
R7
R10
ш 2
44
9
48
4
3 15 21
82
ш 26
ш
3
0
36
43
95
135
22
49
44
82
74
Rear panel of
plasma display
149
(From center of plasma display screen)
(excluding screw
heads and
plasma display)
Display operation panel
(excluding screw
heads and
plasma display)
