Specifications
Power supply: DC 12 V (DC IN terminal)/
DC 7.2 V (Exclusive battery terminal)
Power consumption (using included AC adaptor):
Play Mode: Approx. 22 W (Unit only Approx. 18 W)
Recharge mode (Quick Start “Off”): Approx. 17 W
Recharge mode (Quick Start “On”): Approx. 21 W
Standby mode (Quick Start “Off”): Approx. 0.4 W
Standby mode (Quick Start “On”): Approx. 5 W
AC adaptor:
Power source: AC 100 to 240 V, 50/60 Hz
Power consumption: 42 W
DC output: 12 V, 2500 mA
Battery pack (lithium ion):
Included/Optional: DY-DB30
Voltage: 7.2 V
Capacity (Minimum): 5400 mAh
Optional: DY-DB15
Voltage: 7.2 V
Capacity (Minimum): 4200 mAh
Optional: DY-DB100
Voltage: 7.2 V
Capacity (Minimum): 8100 mAh
Dimensions (W kDkH)
(excluding protrusions and battery):
262 mm (W) k55.1 mm (D)k200.5 mm (H)
(10 5 /
16
qk2 11 /
64
qk7 57 /
64
q)
Mass (Weight):
(including battery) Approx. 1766 g (62.3 oz)
(without battery) Approx. 1531 g (54.0 oz)
Operating temperature range: i5 to i35 oC (i41 to i95 oF)
Operating humidity range: 10 to 80 % RH (no condensation)
LCD screen:
10.1 q WIDE-SVGA LCD (1024k600kRGB)
HDMI AUDIO/VIDEO output:
Number of terminals: 1 system (19pins TypeA)
LAN:
Number of terminals: 1 system (10BASE-T/100BASE-TX)
USB slot:
Number of terminals: 1 system (USB2.0)
SD card slot:
Number of terminals: 1 system
Speaker:
Output: 0.5 W i 0.5 W (8 ≠)
Headphone output:
Output: ‡ 3.5 mm (1/8q) stereo mini jack
Number of terminals: 1 system
Pickup:
Wave length:
405 nm/660 nm/780 nm (BD/DVD/CD)
Laser power:
CLASS II/CLASS II/CLASS I (BD/DVD/CD) HHS/for USA
CLASS 1M/CLASS 1M/CLASS 1M (BD/DVD/CD) IEC/for Canada
Wireless LAN Adaptor
Dimensions (W kHkD)
44 mm (W) k27 mm (H)k72 mm (D)
(1 3 /
4
qk1 1 /
8
qk2 7 /
8
q)
Mass (Weight): Approx. 29 g (1.02 oz)
Antenna: Tx 1, Rx 2
Interface: USB2.0
Standard Compliance:
IEEE802.11n / IEEE802.11a / IEEE802.11g / IEEE802.11b
Transmission system:
MISO-OFDM system, OFDM system, DSSS system
Frequency Range:
IEEE802.11n / IEEE802.11a:
5.15 GHz - 5.35 GHz/5.47 GHz - 5.825 GHz
IEEE802.11g / IEEE802.11b / IEEE802.11n:
2.4 GHz - 2.4835 GHz
Transfer rate (standard) *11 :
IEEE802.11n: Tx Max. 150 Mbps, Rx Max. 300 Mbps
IEEE802.11g / IEEE802.11a: Max. 54 Mbps
IEEE802.11b: Max. 11 Mbps
Access Mode:
Infrastructure mode
Security:
WPA2-PSK (TKIP/AES)
WPA-PSK (TKIP/AES)
WEP (64 bit / 128 bit)
(This unit supports WPA and WPA2 encryption.)
Playable disc:
BD-Video
BD-ROM:
Version 2
BD-RE: Version 3 (Single Layer, Dual Layer),
JPEG
BD-R: Version 2 (Single Layer, Dual Layer),
DivX
*4, *5
DVD-RAM: DVD Video Recording format *10 ,
AVCHD format, JPEG
DVD-R/DVD-R DL: DVD-Video format *1 , DVD-Video
Recording format *1, *10 , AVCHD format *1 ,
DivX *2, *3, *5 , JPEG *2 , MP3 *2
DVD-RW: DVD-Video format *1 , DVD-Video
Recording format *1, *10 , AVCHD format *1
+R/+RW/+R DL: Video *1 , AVCHD format *1
DVD-Video: DVD-Video format
CD-Audio: CD-DA
CD-R/CD-RW: CD-DA, JPEG *2 , MP3 *2 , DivX *2, *5
SD card:
SD Memory Card *6 formatted FAT12,
FAT16, FAT32 *7 , exFAT *9
JPEG, AVCHD format, MPEG-2
USB:
USB Standard: USB 2.0 High Speed
MP3, JPEG, DivX
Format: FAT12, FAT16, FAT32
JPEG *8 :
Pixels: 34 k 34 to 8192 k 8192
Sub Sampling: 4:2:2, 4:2:0
Maximum numbers of folders
≥ CD-R, CD-RW:
99
≥ BD-RE, DVD-RAM, DVD-R, DVD-R DL,
SD card, USB device: 300
Maximum numbers of files
≥ CD-R, CD-RW:
999
≥ BD-RE: 9999
≥ DVD-RAM, DVD-R, DVD-R DL, SD card, USB device: 3000
MP3:
Compression rate: 32 kbps to 320 kbps
Sampling rate: 44.1 kHz, 48 kHz
AVCHD (H.264):
File format: AVCHD format V1.0
HDMI:
480p(525p) / 1080i(1125i) / 720p(750p) /1080p(1125p)
HDMI (x.v.Color™, High Bit rate Audio)
This unit supports “HDAVI Control 5” function.
