100
SPECIFICATIONS
Capacities
Gross Vehicle Weight 765 lbs. (348 kg)
Dry Weight 425 lbs. (193 kg)
Fuel Capacity 2.75 gal. (10.4 l)
Engine Oil Capacity 41 oz. (1200 ml)
Transmission Oil 18.6 oz. (550 ml)
Rear Gearcase Oil 4 oz. (120 ml)
Front Rack 45 lbs. (20 kg)
Rear Rack 70 lbs. (32 kg)
Tongue Weight 30 lbs. (13.6 kg)(Rear rack weight and tongue
weight not to exceed 30 lbs./13.6 kg)
Tow Capacity 300 lbs. (136 kg)
Turn Radius 65 in. (165 cm) unloaded
Ground Clearance 5.7 in. (14.5 cm)
Length 70 in. (178 cm)
Width 42 in. (106.7 cm)
Height 42 in. (106.7 cm)
Seat Height 32 in. (81.3 cm)
Wheel Base 45 in. (114.3 cm)
Engine & Cooling
Engine Model Number / Type 4 Cycle, Single Cylinder
Lubrication Wet Sump
Bore x Stroke 65 x 59
Displacement 196 cc
Compression Ratio 9.2:1 Full Stroke
Engine Cooling Air cooled
Alternator Output (watts) 210w @5000 rpm
Carburetion 1 / 22 mm (VM Type)
Main Jet 108
Pilot Jet 35
Jet Needle 2MKNN-4 clip
Air Screw 1 Turn Out
Ignition DC CDI
Timing 32° ± 2° @ 3000 RPM
Spark Plug Type / Gap NGK CR6HSA / 0.6-0.7 mm
