Lenovo ThinkVision E54 - Manual (Page 11)

9
OPERATING INSTRUCTIONS
General Instructions
The power switch is located at front panel of the monitor. Press the power
switch to turn the monitor on or off. The other control knobs are located at
the base of the monitor (See Figure 3). By changing these settings, the picture
can be adjusted to your personal preferences.
• The power cord must be connected.
• Connect the video cable from the monitor to the video card.
• To turn the monitor on, press the POWER switch to ON position. The
power indicator will light up.
• Your monitor features a unique quick switch system which provides a
picture within seconds after the monitor is switched on.
1
2
3
4
5
6
Figure 3 External Control Knob
EXTERNAL CONTROLS
1. EXIT Key 4. MENU
2. BRIGHTNESS/ 5. Power Indicator
3. CONTRAST/ 6. Power Switch
