Maintenance
36
10.2.1 Accessing Internal Electrical Components
1. Disconnect all power inputs.
2. Remove five screws to remove the front electrical panel cover. SeeFigure 37 and 12 of 13
3. Lift off the panel.
Figure 37 Accessing internal electrical components
Edge of the
Fan Assembly
