Chapter, Cabling, Super – Lenovo 40Y8699 User Manual
Page 23: Multi-burner, Drive, Host, Computer
Chapter
2.
Cabling
the
USB
2.0
Super
Multi-Burner
Drive
to
the
host
computer
The
following
diagrams
may
be
helpful
when
cabling
the
USB
2.0
Super
Multi-Burner
Drive
to
your
host
computer.
Please
note
that
these
diagrams
might
differ
slightly
from
your
hardware.
Cabling
using
the
AC
power
adapter
5
1
USB
connector
2
USB
2.0
Super
Multi-Burner
Drive
3
AC
adapter
4
Standard
USB
cable
assembly
5
Typical
ThinkPad
computer
Figure
2-1.
AC
power
adapter
configuration
©
Lenovo
2006.
Portions
©
IBM
Corp.
2003.
2-1
