29
Technical information
IKEMI Specifications
Signal Connector Level Impedance Notes
Single ended analogue RCA phono 2V rms 300 Ohms
Balanced analogue XLR male 4V rms 600 Ohms pin1 gnd
pin 2 hot
pin 3 cold
SPDIF electrical BNC 0.5V pp 75 Ohms
SPDIF optical TOSLINK
AES/EBU electrical XLR male 1V pp 110 OHMS pin 1 gnd
pin 2 hot
pin 3 cold
Sync Link input RCA phono 0-10 Vdc 10k Ohms Linn use only
Knekt remote in/out RCA phono 4mA na Knekt use only
Mains input IEC 90 - 130Vac
180 - 260Vac manual switch
20 Watts max
Dimensions: 80mm H x 320mm W x 325mm D
(3.15 x 12.6 x 12.8 inches)
Weight: 4.1kg (9 lb)
