Linksys HomeLink HPPO200 User Manual

Page 11

6. Windows will ask you to restart the PC. Click the Yes button.

Repeat steps 1-6 for each PC on your network. When all of your PCs are

configured, the HomeLink Phoneline Router Setup and Installation is

complete.

If you would like, you may continue on to learn more about the

HomeLink Phoneline Router’s Web-based Utility.

3. In the Configuration window, select the TCP/IP protocol line that has

been associated with your network card/adapter. If there is no TCP/IP line
listed, refer to the Appendix to install the TCP/IP Protocol now.

4. Click the Properties button, then choose the IP Address tab. Select

Obtain an IP address automatically. Press the OK button. You have com-
pleted the client settings.

5. Click the OK button. Windows may ask for original Windows installation files.

Supply them as needed (i.e.: D:\win98, D:\win95, c:\windows\options\cabs.,
etc.)

Phoneline 10M Cable/DSL Router

HomeLink™ Series
