Phoneline + 10/100 USB Network Adapter
Specifications
Model Number:
USB100H1
Standards:
IEEE 802.3 IEEE 802.3u, HPNA 1.1, USB v1.0 or
higher
Protocol:
CSMA/CD
Ports:
1 USB Type B Port
2 RJ-11 Standard Modular Telephone Ports (With
Pass-Through)
1 10BaseT/100BaseTX Auto-Sensing RJ-45
RJ-11 and RJ-45 Ports are Mutually Exclusive
Speed:
1Mbps (Phoneline), 10Mbps (Ethernet), 100Mbps
(Fast Ethernet)
Cabling
Phoneline:
Standard Copper Telephone Cable
10/100:
UTP/STP Category 5 (or better)
Topology:
Star (Ethernet and Fast Ethernet) or Daisy Chain
(HomeLink)
Bus Speed:
12Mbps (Buffered) Universal Serial Bus
LED Status Lights:
Activity (ACT), HOMELINK, 10Mbps (10),
100Mbps (100)
Environmental
Dimensions:
3.8" x 2.6" x 1.2" (97 x 66 x 30 mm)
Unit Weight:
5.0 oz. (156 g)
Power:
5v Bus Powered from PC
Certifications:
FCC Class B, CE Mark (Commercial)
Operating Temperature:
32ºF to 122ºF (0ºC to 49ºC)
Storage Temperature:
-4ºF to 158ºF (-20ºC to 70ºC)
Operating Humidity:
10% to 85% Non-Condensing
Storage Humidity:
5% to 90% Non-Condensing
39
