GAS PURGE PUSHBUTTON
The gas solenoid valve will energize but neither the
power source output nor the drive motor will be turned
on. The Gas Purge switch is useful for setting the
proper flow rate of shielding gas. Flow meters should
always be adjusted while the shielding gas is flowing.
B-9
OPERATION
B-9
REAR CONTROLS:
LN-25™ PIPE
1 Gas
Purge
Pushbutton
2 Shielding
Gas
Inlet
3 Electrode
Lead
ITEM
DESCRIPTION
1
2
3
1
Gas Purge Pushbutton
2
Shielding Gas Inlet
3 Electrode
Lead
ITEM
DESCRIPTION
1
2
3
