A-1 INSTALLATION A-1
LN-25™ PIPE
TEMPERATURE RANGE
OPERATION: -40°F to 104°F (-40°C to 40°C)
STORAGE: -40°F to 185°F (-40°C to 85°C)
INPUT VOLTAGE and CURRENT
TECHNICAL SPECIFICATIONS – LN-25™ PIPE (K2614-10)
HEIGHT WIDTH DEPTH WEIGHT
14.8 Inches 8.7 Inches 22.2 Inches 41 lbs
(376 mm) ( 221 mm) (589 mm) (18.6 kg)
Handle folded down
PHYSICAL DIMENSIONS
INPUT VOLTAGE ± 10%
40 VDC
INPUT AMPERES
4A
RATED OUTPUT @ 104°F (40°C)
DUTY CYCLE
60% rating
100% rating
INPUT AMPERES
450
325
GEARING - WIRE FEED SPEED RANGE-WIRE SIZE
WFS RANGE
50 – 700 ipm
(1.3 – 17.7m/min)
WFS RANGE
50 – 700 ipm
(1.3 – 17.7m/min)
WIRE SIZES
.023 – 1/16"
(0.6 – 1.6mm)
WIRE SIZES
.030 - 5/64
(0.8 - 2.0mm)
GEARING
K2614-10
GMAW FCAW
