Lopi Freedom Fireplace Insert - Manual (Page 6)

6 Features & Specifications
© Travis Industries 100-01162 4041105
Installation Options:
•
Masonry Fireplace Insert
WARNING: Do not install this fireplace insert into a
factory-built metal (Z.C.) fireplace.
Features:
•
EPA Phase II Approved
•
2.9 Cubic Foot Firebox Volume
•
Single Operating Control
•
Accepts Logs Up to 24" Long
•
Steel Plate Construction (5/16" & 3/16")
•
Heavy Duty Refractory Firebrick
•
Optional High-Tech Blower
Heating Specifications:
Approximate Maximum Heating Capacity (in square feet)* 1,200 to 2,250 (Extended)
1,200 to 2,000 (with Flush Kit)
Maximum BTU's per Hour (Cord Wood Calculation) 73,300
Overall Efficiency (Oregon Method) 71.1 %
Maximum Burn Time Up to 12 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside
temperature. It is also affected by the quality and moisture level of the fuel.
Dimensions:
21-1/4"
5-5/8"
Fireplace Opening -
Extended Position (stock)
21-3/4"
Measure side and
top clearances from
the top plate.
Fireplace Opening -
Flush Position (requires kit)
13-1/2"
18-7/8"
7"
1-5/8"
29-1/4"
20-1/4"
Weight = 455 lbs.
Figure 1
Emissions:
3.2 Grams Per Hour (EPA Phase II Approved) – Tests conducted by E.E.S.P.C.
