Lopi Freedom Fireplace Insert - Manual (Page 13)

Installation
(for qualified installers only)
13
© Travis Industries 100-01162 4041105
Insert with Direct Connection (Masonry Fireplace)
Block-off plate or
damper adapter
Remove
damper
or wire it
open
Airtight
Insulated
Clean-Out
Stainless steel
chimney connector
must Extend 1' past
the block-off plate or
to the flue liner
Combustible Mantle
Flue
Liner
See the section
"Insert Placement
Requirements" for
minimum clearances
and hearth required.
Surround Panels
Figure 7
NOTE:
Direct connections require installation of an airtight block-off plate or damper adapter (see "Block-off Plate
Installation" on page 11).
