48
Section 8: Troubleshooting
Z44 & Z52 (S/N 526171 & Above) Accu-Z Razor ® Zero Turn Mowers 357-187M 7/22/10
Table of Contents
Section 8: Troubleshooting
Symptoms Probable Causes Suggested Remedies
Starting motor does not crank Control arms are not in park position or
park switch is out of adjustment Place control arms in neutral and full out. Re-
adjust park position switch
Blade Engagement switch is engaged Disengage blade switch
Weak or dead battery Recharge or replace
For additional causes See engine manual
Engine cranks but does not start No fuel in fuel tank Fill fuel tank
Fuel tank valve turned to “OFF” Select a fuel tank with gasoline
See Figure 5-9 on page 36
Fuel tank valve turned to an empty tank Switch Left/Right tank valve
See Figure 5-9 on page 36
Fuel filter or fuel line is plugged Replace fuel filter or fuel line
Numerous See engine manual
Engine:
Runs with continuous misfiring or
engine runs unevenly or erratically Numerous See engine manual
Grass cutting is ragged or uneven Dull, bent or broken cutting blades Sharpen or replace cutting blades
Deck full of wet sticky grass Clean underside of deck
Cutting Blades are not operating at full
engine speed Increase engine rpms to full speed (3600 rpm)
Check engine speed with Land Pride Inductive
Tachometer, Part No. 890-909C
Belt over center take-up is loose Tension over center take-up
Worn or broken belt Replace worn and broken belts
Deck is not level Check air pressure in all 4 tires
Make level adjustments to the deck
Loss of power or system will not
operate in either direction Bypass valve rods are disengaged Engage bypass valve rods
Linkage bolt is loose or lost Replace linkage bolt
Bad pump belt and/or idler pulley Replace belt and/or idler pulley Tighten idler
pulley if loose
Loose or lost idler pulley bolt Retention idler pulley and retighten or replace
idler bolt
Restrictions in air cleaner Service air cleaner
Internal interference or leakage in Hydro-
Drive See your dealer
Insufficient hydraulic oil supply Have dealer check hydro-drive
Poor compression See your dealer
Steering linkage needs adjustment Adjust linkage
Air in system Check filter & fittings
For additional causes See engine manual
Overheating Air intake screen or cleaning fins clogged Clean screen and fin
Not operating engine at rated speed Increase engine speed to 3600 rpm
For additional causes See engine manual
