8
COMPONENTS LIST
HARDWARE
ITEM NO. QTY. DESCRIPTION
39 14 3/8” WASHER
40 4 M10 X 30MM SCREW
41 8 M10 X 70MM SCREW
42 4 M12 X 80MM SCREW
43 8 1/2” WASHER
44 4 M12 HEX NYLOCK NUT
45 2 M10 X 50 HEX TENSION SCREW
46 2 GUIDE ROD RETAINER
47 4 M4 X 0.7MM ZINC PHILLIPS PAN HEAD SCREW
48 2 M10 X 20MM SCREW
49 2 RETAINING RING
50 4 #10-32 X 3/4” PHILLIPS PAN HEAD SCREW
51 2 M6 X 60MM SCREW
52 2 1/4” WASHER
53 4 M10 HEX NYLOCK NUT
54 8 M4 ZINC PHILLIPS PAN HEAD SCREW
55 2 #6 X 3/8” BLACK PHILLIPS PAN HEAD SCREW
REQUIRED TOOLS
ADJUSTABLE WRENCH
EXTERNAL SNAP RING PLIERS
PHILLIPS SCREW DRIVER
ALLEN WRENCHES (4mm, 7mm, 8mm)
WRENCHES (13mm, 17mm, 19mm)
