COMPONENT ASSEMBLY II LEGEND ______________________________________
Page 6
G4-001 G4 HOME GYM
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 8582201 CAP, END 75 X 50
2 2 8582101 LAT BAR HOOK COVER - 3/8 ID X 4-3/8 L
3 1 8584301 ADJUSTABLE GLIDE
4 1 8589401 GS4 ALUMINUM LOGO
5 1 8599401 SLEEVE, AL 13 OD X 10 ID X 12L
6 1 8582001 T-HANDLE SPRING PIN
7 1 8599101 BUMPER
8 1 8580401 KNOB, SEAT ADJUSTER
9 1 3102904 3/8-16X3 UNS HEX FHB G2 ZN
10 10 3102807 NUT, NYLOCK 3/8-16 LOW HT
11 2 8589701 END CAP, 2 SQ
12 9 3102905 3/8-16 X 3-3/4 UNS HEX FHB G2 ZN
13 2 3102965 3/8-16 X 3/4 UNS HEX FHB G2 ZN
14 4 3102514 WASHER, FLAT 3/8 IN SAE ST ZN
15 1 7611601 V PULLEY
