COMPONENT ASSEMBLY I LEGEND
______________________________________
Page 4
G4-001 G4 HOME GYM
ITEM NO. QTY. PART NO. DESCRIPTION 31 1 8591201 T HANDLE SPRING PIN
1 1 8589201 ASSY, FRAME, G4 32 2 8589801 CAP, COVER 2 X 2
2 1 8589501 ASSY, BASE, G4 33 2 8591601 GUARD, 3-1/2 PULLEY
3 2 8602501 BASE PLATE 34 2 8578901 PLATE, PULLEY
4 1 8587801 WLDMT, FOOT PLATE 35 1 7316201 3/4 X 17-7/8 TUBE
5 1 8602601 BOOM PLATE LEFT 36 1 7316202 3/4 X 18-7/8 TUBE
6 1 8602701 BOOM PLATE RIGHT 37 1 7316203 3/4 X 21 TUBE
7 1 8589901 ASSY, LEFT REAR UPRIGHT 38 2 8591501 ASSY, BEARING BLOCK
8 1 8590201 ASSY, RIGHT REAR UPRIGHT 39 1 8594301 PAD, CONSUMER, SEAT
9 1 8590401 ASSY, LEFT PEC FLY ARM 40 1 8594201 PAD, CONSUMER, BACK
10 1 8590701 ASSY, RIGHT PEC FLY ARM 41 6 8578401 PAD, ROLLER
11 2 8599901 ASSY, PEC FLY HANDLE 42 12 8584201 WASHER, PLASTIC
12 1 8591001 ASSY, PRESS ARM 43 6 8598001 AL CAP, ROLLER PAD END
13 1 8590901 WLDMT, BRACE 44 6 3268301 CAP SCREW, BTN HD 3/8-16 BO
14 1 8577801 ASSY, LEG PEDESTAL 45 1 8587601 WEIGHT STACK PIN
15 1 8585201 ASSY, SEAT ADJUST 46 2 3108002 CUSHION, WEIGHT STACK 3/4 ID
16 1 8591301 ASSY, PRESS ARM SUPPORT FRAME 47 2 8588601 WLDMT, WEIGHT STACK SPACER
17 1 8599801 PRESS ARM ADJUST PLATE 48 2 6224501 SOCKET BUSHING
18 1 8603301 BACK INCLINE ADJUSTMENT 49 2 8588501 COLLAR, SHAFT, AL 32.5 OD X 11.1H
19 1 8595501 PTD ASSY, SHROUD BRKT - TOP 50 2 3247701 M4 X 0.7 X 3 HZS NO CUP ST BO
20 1 8595601 PTD ASSY, SHROUD BRKT - BTM 51 2 6523401 GUIDE ROD, 3/4 OD X 72-3/8
21 1 8597401 SHROUD, LEFT 52 1 8603601 AB STRAP
22 1 8597501 SHROUD, RIGHT 53 1 6409101 STRAP, ANKLE STANDARD
23 2 8595701 PLATE, DOUBLE PULLEY 54 1 6075906 CHAIN, 12 LINK
24 1 8596901 ASSY, DOUBLE FLOAT PULLEY BRKT 55 4 3103801 LINK, SNAP 5/16 DIA
25 1 8597301 BRKT, FLOATING PULLEY 56 1 8588301 ASSY, LOW ROW BAR
26 2 8603501 L CABLE RETAINER 57 1 8598701 ASSY, LAT BAR, G4
27 1 8595401 4-1/2 CABLE GUARD 58 2 8598901 HAND GRIP - 25MM OD X 580L
28 1 8599501 SHAFT, PRESS ARM PIVOT 59 2 7662801 RING, GRIP 1.25 OD
29 1 8602901 PRESS ARM SUPPORT PIVOT 60 8 3247701 M4 X 0.7 X 3 HZS NO CUP ST BO
30 4 3268501 BUSHING 31 OD X 25.1 ID X 20H 61 2 7662901 CAP; GRIP 1.25 OD
