Gun Drive Unit Assembly, Includes: K110 1
1 Mounting Clamp M9108 1
2 Thumb Screw T9078-3 1
3 Control Cable and Plug S11837 1
5 Grommet T9274-1 2
6 Truss Head Screw 8-32x5/8 2
7 Insulator Bushing T11215-2 2
8 Drive Wheel M9122 1
9 Hollow Set Screw, Cup Point S11604-13 1
11 Resistor T12731-3 1
14 Reversing Switch T13111 1
15 Insulating Plate T11221 1
16 Control Box Back M9027-1 1
17 Control Box Front M9693 1
19 Dial Plate S11163 1
20 Knob T11157 1
21 Insulation T11228 1
22 Rheostat T10812-9 1
23 Gear Box assembly See P-107-Y 1
26 Motor S11162 1
27 Adapter Plate M9109 1
28 Mounting Clamp Extension M9142 1
05-10-2005
Use only the parts marked “X” in the column under the
heading number called for in the model index page.
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-107-X P-107-X
# Indicates a Change This Printing
MECHANIZED HAND TRAVEL UNIT: K110
Pa
r
t
N
u
m
be
r
s
P
a
r
t
N
u
m
be
r
s
P
a
r
t
N
u
m
be
r
s
P
a
r
t
N
u
m
be
r
s
L3865
4-3-81E
27
26
16
14
17
19
20
22
11
21
23
28
9
8
15
7
6
2 1
5
3
METHOD OF MOUNTING EXTENSION
NOTE: FOR PROPER LEAD
CONNECTIONS SEE
WIRING DIAGRAM
