1 Wire Reel Support Assembly L6831-3 ø 1 X X X
2 Wire Reel Shaft Assembly M14511 1 X • •
2 Spindle Assembly M14935 1 • X X
3 Readi-Reel Adapter K363-P 1 X X X
4 Insulating Washer S10773-52 1 X • •
5 Insulator Bushing T14816 1 X • •
5 Bushing T14844 1 • X •
6 Brake Disc Spacer T12967-1 1 X • •
7 Plainwasher S9262-14 1 X • •
8 Lockwasher E106A-15 1 X X X
9 Hex Head Screw 1/2-13 x 1.00 1 X • •
9 Hex Head Screw 1/2-13 x 1.75 1 • X X
10 Cable Clamp S16819 1 X X X
Thread Rolling Screw S9225-8 2 X X X
12 Retaining Collar S13871 1 X • •
13 Readi-Reel Decal T13086-44 1 X X X
14 Plainwasher S9262-14 1 • • X
15 Retaining Collar M14587-1 1 • • X
Optional - Not Illustrated
10# Wire Reel Spacer
S18221 1 X X X
05-09-2002
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-125-N.1 P-125-N.1
# Indicates a Change This Printing
Su
b
A
s
s
e
m
b
l
y I
l
l
u
st
r
a
t
i
o
n
S
u
b
A
sse
m
b
l
y I
l
l
u
st
r
a
t
i
o
n
S
u
b
A
sse
m
b
l
y I
l
l
u
st
r
a
t
i
o
n
S
u
b
A
sse
m
bl
y
I
l
l
u
s
t
r
a
t
i
o
n
For Obsolete Molded Plastic Spindle Assembly Use Column 1.
For Obsolete Aluminum Spindle Assembly Use Column 2.
For Current Molded Plastic Assembly Use Column 3.
#
ø
This part is obsolete and no longer available.
