1 Wire Reel Support Assembly L6831-3 ø 1 X
2 Wire Reel Housing, Includes: S17069-2 1 X
Housing M11940 1 X
Wire Sheath T14800 1 X
Wire Sheath Insulating Block S17068 1 X
Support Washer S15094 1 X
3 Axle S13954 1 X
4 Round Head Screw #10-24 x .875 4 X
Lockwasher E106A-1 4 X
5 Washer T13984 1 X
6 Axle Housing S13953 1 X
7 Wire Reel Cover (Back) M11574-2 2 X
8 Self Tapping Screw S8025-22 4 X
9 Spring T11862-8 1 X
10 Plainwasher S9262-45 1 X
11 Insulating Washer S10773-49 1 X
12 Hex Head Screw 5/16-18 x .75 1 X
Lockwasher E106A-3 1 X
Plainwasher S9262-61 1 X
13 Wire Reel Cover (Front) M11574-2 1 X
14 Axle Nut S13956 1 X
20 Housing Cover M11578 1 X
Decal S118932 1 X
21 Cover Retaining Strap Assembly S15891 1 X
22 Cable Clamp S16819 1 X
Thread Cutting Screw S9225-8 2 X
23 Coil Support Disc S17060 1 X
24 Thread Cutting Screw S9225-30 2 X
05-09-2002
Use only the parts marked “X” in the column under the
heading number called for in the model index page.
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-125-O.1 P-125-O.1
# Indicates a Change This Printing
Su
b
A
s
s
e
m
b
l
y I
l
l
u
st
r
a
t
i
o
n
S
u
b
A
sse
m
b
l
y I
l
l
u
st
r
a
t
i
o
n
S
u
b
A
sse
m
b
l
y I
l
l
u
st
r
a
t
i
o
n
S
u
b
A
sse
m
bl
y
I
l
l
u
s
t
r
a
t
i
o
n
#
ø
This part is obsolete and no longer available.
