27. Re-attach the positive output terminal cable.
28. Set the fuel tank into position on the rails and
secure it with the four bolts, washers, and nuts.
29. Attach the fuel return line at the top of the fuel tank
(Diesel engine only). Remove the plug from the
fuel line and attach it to the fuel bowl.
30. Perform the replacement procedures according to
each of the following:
Alternator Stator Removal and Replacement
Alternator Rotor Removal and Replacement
Before installing the machine case top and sides,
be sure to replace any cable ties cut during disas-
sembly.
TROUBLESHOOTING & REPAIR
F-52 F-52
Classic III and IIID Retur
n to Section TOC
Retur
n to Section TOC
Retur
n to Section TOC
Retur
n to Section TOC
Retur
n to Master TOC
Retur
n to Master TOC
Retur
n to Master TOC
Retur
n to Master TOC
GENERATOR FRAME REMOVAL
AND REPLACEMENT (continued)
