TROUBLESHOOTING & REPAIR

F-44

Classic III and IIID

FIGURE F.18 - LEAD DISCONNECTION POINTS

YELLOW AND WHITE WIRE
IN-LINE CONNECTORS;
YELLOW LEADS; BLACK
CURRENT TRANSFORMER
LEAD

ALL LOCATED BEHIND
CASE FRONT

ALTERNATOR STATOR REMOVAL

AND REPLACEMENT

(continued)

FIGURE F.19- LEAD DISCONNECTION – CIRCUIT BREAKER, RECEPTACLES, FIELD BRIDGE RECTIFIER

230 VAC RECEPTACLE

CB1 CIRCUIT BREAKER

115 VAC RECEPTACLE

CB4 CIRCUIT BREAKER

FIELD FUSE HOLDER

FIELD RECTIFIER BRIDGE
