Gas Valves
9/03—Printed in U.S.A. 4
ITEM PART DESCRIPTION MODEL
NO. NO. NO. 5
Pilot & Buner Assemblies Con’t.
13 MAN2900 GAS MANIFOLD 045
13 MAN2901 GAS MANIFOLD 075 & 090
13 MAN2902 GAS MANIFOLD 135
13 MAN2903 GAS MANIFOLD 180
13 MAN2904 GAS MANIFOLD 225
13 MAN2905 GAS MANIFOLD 270
13 MAN2906 GAS MANIFOLD 315
13 MAN2907 GAS MANIFOLD 360
14 ORF2904 ORIFICE, MAIN BNR. NAT. ALL
14 ORF2901 ORIFICE, MAIN BNR. LPG . ALL
17 WRE2030 IGNITION CABLE ALL F9/M9
18 PLT2903 THERMOCOUPLE 045-180
18 PLT2904 THERMOCOUPLE 225-270
Gas Valves
15 VAL2922 GAS VALVE, NAT. F1 045-135
15 VAL2920 GAS VALVE, NAT. F1 180-270
15 VAL4901 GAS VALVE, LPG. F1 045-135
15 VAL2921 GAS VALVE, LPG. F1 180-270
15 VAL2904 GAS VALVE, NAT. F9 045-135
15 VAL2928 GAS VALVE, NAT. F9 180-360
15 VAL2905 GAS VALVE, LPG. F9 045-135
15 VAL2929 GAS VALVE, LPG. F9 180-360
15 VAL2930 GAS VALVE, NAT. M9 45-135
15 VAL2932 GAS VALVE, LPG. M9 45-135
15 VAL2931 GAS VALVE, NAT. M9 180-360
15 VAL2933 GAS VALVE, LPG. M9 180-360
Miscellaneous
4 JKR2059 V-BAFFLE 045
4 JKR2060 V-BAFFLE 075 & 090
4 JKR2061 V-BAFFLE 135
4 JKR2062 V-BAFFLE 180
4 JKR2179 V-BAFFLE 225 & 199
4 JKR2180 V-BAFFLE 270
4 JKR2181 V-BAFFLE 315
4 JKR6182 V-BAFFLE 360
21 WRE2911 WIRE HARNESS ALL F1
21 WRE2912 WIRE HARNESS ALL F9
22 WRE2915 JUMPER PLUG/VENT DAMPER ALL RW & RB 315-360
25 RLV2005 RELIEF VALVE, PRESSURE ONLY ALL RB
25 RLV2006 RELIEF VALVE, T & P ALL RW
27 TST2301 BULB WELL ALL
-- GLV3890 OUTLET TEE FOR ITEMS 24 & 25 (1.5" X .75" X 1.5") with 3/8" TAPPING ALL RW
29 CFK3045 COMB. FLOOR KIT 045
29 CFK3090 COMB. FLOOR KIT 075 & 090
29 CFK3135 COMB. FLOOR KIT 135
29 CFK3180 COMB. FLOOR KIT 180
29 CFK3225 COMB. FLOOR KIT 225 & 199
29 CFK3270 COMB. FLOOR KIT 270
29 CFK3315 COMB. FLOOR KIT 315
29 CFK3360 COMB. FLOOR KIT 360
31 GKT2901 GASKET, FLANGE 1.5" ALL RW
32 WTR3902 FLANGE 1.5" ALL RW
-- RLY2707 PUMP DELAY ALL RW
Options (Not Pictured)
-- LPK3900 NAT. TO LPG CONV. KIT, F1 045-090
-- LPK3901 NAT. TO LPG CONV. KIT, F1 135-270
-- LPK3903 NAT. TO LPG CONV. KIT, F9 045-090
-- LPK3904 NAT. TO LPG CONV. KIT, F9 135-360
-- TST2015 MANUAL RESET HI LIMIT OPTIONAL
-- WTR2040 FLOW SWITCH OPTIONAL
-- WTR2528 LOW WATER CUT OFF OPTIONAL
-- WTR2532 PROBE FOR LWCO OPTIONAL
