ITEM
PART
DESCRIPTION
MODEL
NO.
NO.
NO.
Heat Exchangers
5
HEX3842
HEAT EXCHANGER H
RB45
5
HEX3843
HEAT EXCHANGER H
RB75/90
5
HEX3844
HEAT EXCHANGER H
RB135
5
HEX3845
HEAT EXCHANGER H
RB180
5
HEX3805
HEAT EXCHANGER H (RW before serial F00)
RW75/90
5
HEX3806
HEAT EXCHANGER H (RW before serial F00)
RW135
5
HEX3807
HEAT EXCHANGER H (RW before serial F00)
RW180
5
HEX3808
HEAT EXCHANGER H (RW before serial F00 & all RB)
199/225
5
HEX3809
HEAT EXCHANGER H (RW before serial F00 & all RB)
270
5
HEX3810
HEAT EXCHANGER H (RW before serial F00 & all RB)
315
5
HEX3811
HEAT EXCHANGER H (RW before serial F00 & all RB)
360
5
HEX3815
HEAT EXCHANGER CUPRO NICKEL H (RW before serial F00)
RW75/90
5
HEX3816
HEAT EXCHANGER CUPRO NICKEL H (RW before serial F00)
RW135
5
HEX3817
HEAT EXCHANGER CUPRO NICKEL H (RW before serial F00)
RW180
5
HEX3825
HEAT EXCHANGER CUPRO NICKEL H (RW before serial F00 & ALL RB)
199/225
5
HEX3826
HEAT EXCHANGER CUPRO NICKEL H (RW before serial F00 & ALL RB)
270
5
HEX3827
HEAT EXCHANGER CUPRO NICKEL H (RW before serial F00 & ALL RB)
315
5
HEX3828
HEAT EXCHANGER CUPRO NICKEL H (RW before serial F00 & ALL RB)
360
5
HEX3042
HEAT EXCHANGER HLW (after serial F00)
RW75/90
5
HEX3043
HEAT EXCHANGER HLW (after serial F00)
RW135
5
HEX3044
HEAT EXCHANGER HLW (after serial F00)
RW180
5
HEX3036
HEAT EXCHANGER HLW (after serial F00)
RW199/225
5
HEX3037
HEAT EXCHANGER HLW (after serial F00)
RW270
5
HEX3038
HEAT EXCHANGER HLW (after serial F00)
RW315
5
HEX3039
HEAT EXCHANGER HLW (after serial F00)
RW360
5
HEX3045
HEAT EXCHANGER CUPRO NICKEL HLW (after serial F00)
RW75/90
5
HEX3046
HEAT EXCHANGER CUPRO NICKEL HLW (after serial F00)
RW135
5
HEX3047
HEAT EXCHANGER CUPRO NICKEL HLW (after serial F00)
RW180
5
HEX3048
HEAT EXCHANGER CUPRO NICKEL HLW (after serial F00)
RW199/225
5
HEX3049
HEAT EXCHANGER CUPRO NICKEL HLW (after serial F00)
RW270
5
HEX3050
HEAT EXCHANGER CUPRO NICKEL HLW (after serial F00)
RW315
5
HEX3051
HEAT EXCHANGER CUPRO NICKEL HLW (after serial F00)
RW360
Pumps
26
ARM3045PBF
PUMP, WTR. HEATER
ALL RW
Controls
8
RLY2042
RELAY, PUMP
ALL RB
9
RLY2023
IGNITION MODULE
ALL F9
10
TRF2004
TRANSFORMER 50V.A.
ALL
16
HLC2904
ROLLOUT SWITCH
045 - 180
16
HLC2905
ROLLOUT SWITCH
225 & 270
19
TST2902
OPERATOR
ALL RB
19
TST3920
OPERATOR
ALL RW
19
TST3910
LIMIT
ALL RW
19
TST3911*
HI LIMIT (RW F-1 TO SERIAL NUMBER F966718)
ALL RB/RW
19
TST2600
OVERHEAT, LIMIT MANUAL RESET (RW F-1 BEGINNING SERIAL NUMBER F966719)
RW 90 - 270 (F-1)
20
MSC2320
TERMINAL BOARD
ALL
24
GTP2900
T & P GAUGE
ALL RB
24
GTP3000
TEMPERATURE GAUGE
ALL RW
28
HLC2903
SPILL SWITCH
045 - 090
33
WRE2914
WIRING HARNESS, VENT DAMPER
ALL
--
RLY2714
RELAY, ADJUSTABLE (F1's ONLY) [RW F-1 TO SERIAL NUMBER F966718]
RW 90 - 270 (F-1)
--
RLY2900
3
RELAY, 24V. (F1's ONLY) [RW F-1 TO SERIAL NUMBER F966718]
RW 90 - 270 (F-1)
Pilot & Burner Assemblies
11
BNR2902
MAIN BURNER
ALL
12
PLT2901
PILOT, BNR, NAT. F1
045 - 090
12
PLT2902
PILOT, BNR, LPG. F1
045 - 090
12
PLT2016
PILOT, BNR, NAT. FI
135-270
12
PLT2017
PILOT, BNR, LP FI
135-270
12
PLT2905
PILOT, BNR, NAT. F9/M9
135-270
12
PLT2907
PILOT, BNR, LPG. F9/M9
ALL
12
PLT2303
PILOT, BNR, NAT. F9/M9
045-090
