Page 8: Table 4, Drycooler performance data
4
P
ERFORMANCE
D
ATA
Table 4
Drycooler performance data
Model
Number
GPM
Range
No. of
Circuits
MBH/°F Initial Temperature Difference
1.5 GPM/CIR
2.0 GPM/CIR
2.5 GPM/CIR
3.0 GPM/CIR
MBH/ITD PD ft. water MBH/ITD PD ft. water MBH/ITD PD ft. water MBH/ITD PD ft. water
Standard Models
033
6-12
4*
1.3
4.2
1.5
6.2
1.6
9.2
1.7
12.8
069
6-12
4
1.8
7.3
2.1
11.4
2.3
17.0
2.4
23.6
12-24
8*
2.3
3.9
2.5
6.0
2.7
8.9
2.8
12.4
092
9-18
6
2.7
7.0
3.0
11.7
3.3
16.7
3.5
23.0
18-36
12'
3.2
3.7
3.5
6.2
3.7
8.7
3.8
12.1
24-48
16
3.4
3.0
3.6
4.6
3.8
6.3
3.9
8.7
109
12-24
8
3.3
7.1
3.7
11.3
3.9
16.8
4.1
23.3
24-48
16*
3.9
3.8
4.1
6.0
4.3
8.2
4.5
11.4
112
24-48
16*
4.2
4.6
4.5
7.3
4.7
10.2
4.8
14.1
39-78
26
4.5
2.6
4.7
4.4
4.9
6.6
5.0
9.2
139
12-24
8
3.6
6.2
4.1
9.8
4.6
14.6
4.9
20.2
24-48
16*
4.5
3.3
5.0
5.2
5.4
7.1
5.6
9.8
174
24-48
16*
5.8
4.7
6.5
7.5
6.9
10.5
7.3
14.5
36-72
24
6.4
3.2
7.0
4.9
7.4
7.3
7.6
10.1
197
24-48
16*
6.5
6.2
7.3
9.9
7.9
14.1
8.2
19.4
48-96
32
7.7
3.0
8.3
5.0
8.7
7.0
8.9
9.8
225
24-48
16
7.1
7.4
8.0
12.0
8.6
17.2
9.0
23.9
39-78
26*
8.1
4.4
8.8
7.4
9.2
11.0
9.5
15.2
260
24-48
16
7.5
6.4
8.7
10.2
9.5
14.7
10.1
20.3
36-72
24*
9.7
4.4
9.7
6.8
10.4
10.4
10.9
14.0
310
24-48
16
8.3
8.4
9.7
13.5
10.7
19.5
11.4
26.9
48-96
32*
10.7
4.1
11.7
6.9
12.4
9.8
12.9
13.6
350
24-48
16
9.2
12.2
10.9
20.9
12.1
29.1
12.9
40.2
48-96
32*
12.3
6.0
13.4
10.1
14.1
14.6
14.6
20.2
72-144
48
13.4
4.2
14.2
6.7
14.8
10.0
15.1
13.5
352
24-48
16
8.8
8.1
10.4
13.1
11.6
18.9
12.5
26.2
36-72
24*
10.6
5.5
12.1
8.7
13.1
12.9
13.9
17.9
419
24-48
16
9.5
10.6
11.4
17.3
12.9
25.1
14.0
36.7
48-96
32*
13.2
5.2
14.7
8.8
15.7
12.7
16.5
17.5
466
39-78
26
13.1
7.9
15.0
13.2
16.2
19.6
17.1
27.1
60-120
40*
15.2
5.3
16.7
8.6
17.6
12.7
18.3
17.6
491
24-48
16
10.1
15.6
12.5
25.6
48-96
32
14.9
7.7
16.6
12.9
17.7
18.9
18.4
26.1
72-144
48*
16.7
5.3
18.0
8.6
18.8
12.8
19.3
17.4
620
48-96
32
16.7
8.0
19.4
13.3
21.4
19.4
22.8
26.9
96-192
64*
21.4
4.1
23.5
6.8
24.8
9.8
25.8
13.6
650
60-120
40
19.9
8.0
22.7
13.1
24.6
19.5
26.0
27.0
78-156
52*
22.0
6.3
24.4
10.2
26.1
15.2
27.2
20.6
120-240
80
24.6
4.1
26.5
6.7
27.8
9.9
28.7
13.4
700
48-96
32
18.5
11.8
21.8
19.8
24.1
29.0
96-192
64*
24.6
6.0
26.8
10.0
28.2
14.6
29.2
20.2
144-288
96
26.7
4.0
28.5
6.7
29.5
9.8
30.2
13.5
790
48-96
32
18.9
10.2
22.8
17.1
25.7
25.0
96-192
64*
26.4
5.2
29.4
8.7
31.5
12.6
33.0
17.5
880
78-156
52
26.2
8.1
29.9
13.1
32.4
19.5
34.2
26.6
120-240
80*
30.4
5.2
33.4
8.5
35.3
12.7
36.6
17.3
940
48-96
32
20.2
15.3
25.0
25.4
96-192
64
29.8
7.7
33.2
12.9
35.4
18.8
36.8
26.0
144-288
96*
33.4
5.1
35.9
8.6
37.5
12.6
38.6
17.4
