6
D
IMENSIONAL
D
ATA
Figure 4
Dimensional data—1-4 fan models
Figure 5
Dimensional data—6 & 8 fan models
Figure 6
Typical footprint and unit anchor plan
Eyebolts for lifting
condenser provided on
4, 6 & 8 fan models only
Height to top
of fan guard
43-1/8"
(1095mm)
37-7/8"
(962mm)
L
C
18" (457mm)
43-3/16"
(1097mm)
70"
(1778mm)
43-9/16"
(962mm)
Center leg provided on 4 & 8 fan models only
Outlet/inlet connections
86-3/4"
(2203mm)
Center leg provided on 4 & 8 fan models only
18" (457mm)
C
37-7/8"
(962mm)
Height to top
of fan guard
43-1/8"
(1095mm)
70"
(1778mm)
L
87-1/8"
(2213mm)
36" (914.4mm)
clearance
recommended on
all sides for
proper operation
and component
access
4-1/4"
(108mm)
1-3/4"
(44.5mm)
1-3/4"
(44.5mm)
4-1/4"
(108mm)
1"
(25.4mm)
1"
(25.4mm)
C
A
B
