EXTERNAL EQ
UIPMENT SETUP
19
When connecting HDMI to DVI cable
Connect the PC audio output to the D DV VII//P PC C A AU UD DIIO O
II N N jack on the set.
Connect the DVI output of the PC to the H HD DM MII//D DV VII
II N N jack on the set.
1. How to connect
2. How to use
■ Turn on the PC and the TV.
■ Select H H D D M M II input source by using the 1 1 -- 3 3 -- 3 3
button on the remote control.
2
1
When connecting D-sub 15pin cable
Connect the PC audio output to the D DV VII//P PC C A AU UD DIIO O
II N N jack on the set.
Connect the RGB output of the PC to the P P C C II N N jack
on the set.
1. How to connect
2. How to use
■
Turn on the PC and the TV.
■ Select P PC C input source by using the 1 1 -- 3 3 -- 4 4 button on the
remote control.
2
1
RGB OUTPUT AUDIO
1
2
■ This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings.
PC SETUP
DVI-PC-OUTPUT AUDIO
1
2
