WELDER OPERATION

DUTY CYCLE

Duty Cycle is the percentage of time the load is being

applied in a 10 minute period. For example a 60% duty

cycle, represents 6 minutes of load and 4 minutes of no

load in a 10 minute period.

ELECTRODE INFORMATION

For any electrode the procedures should be kept with-

in the rating of the machine. For information on elec-

t r o d e s

a n d

t h e i r

p r o p e r

a p p l i c a t i o n

s e e

(www.lincolnelectric.com) or the appropriate Lincoln

publication.

The VANTAGE 400 (CE) can be used with a broad range

of DC stick electrodes. The MODE switch provides two

stick welding settings as follows:

CONSTANT CURRENT (CC-STICK) WELDING

The CC-STICK position of the MODE switch is designed

for horizontal and vertical-up welding with all types of

electrodes, especially low hydrogen. The OUTPUT CON-

TROL dial adjusts the full output range for stick welding.

B-5

OPERATION

B-5

VANTAGE

®

400 (CE)

NOTE: If the unit fails to start turn Run/Stop switch

to off and repeat step 3 through step 7 after

waiting 30 seconds.

• Do not allow the starter motor to run continuously

for more than 20 seconds.

• Do not push the START button while the engine

is running because this can damage the ring

gear and/or the starter motor.

• If the Engine Protection or Battery Charging

Lights do “not” turn off shortly after starting the

engine shut off the engine immediately and

determine the cause.

------------------------------------------------------------------------

NOTE: When starting for the first time, or after and
extended period of time of not operating, it will take
longer than normal to start because the fuel pump
has to fill the fuel system. For best results, bleed the
fuel system as indicated in Maintenance Section of
this manual.

STOPPING THE ENGINE

Remove all welding and auxiliary power loads and

allow the engine to run at low idle speed for a few

minutes to cool the engine.

STOP the engine by placing the RUN-STOP switch in

the STOP position.

NOTE: A fuel shut off valve is located on the fuel pre-

filter.

CAUTION

The ARC CONTROL dial sets the short circuit current

(arc-force) during stick welding to adjust for a soft or

crisp arc. Increasing the number from -10(soft) to

+10(crisp) increases the short circuit current and pre-

vents sticking of the electrode to the plate while welding.

This can also increase spatter. It is recommended that

the ARC CONTROL be set to the minimum number

without electrode sticking. Start with the dial set at 0.

NOTE:

Due to the low OCV with the VRD on, a

very slight delay during striking of the electrodes

may occur. Due to the requirement of the resis-

tance in the circuit to be low for a VRD to operate, a

g o o d m e t a l - t o - m e t a l c o n t a c t m u s t b e m a d e

between the metal core of the electrode and the

job. A poor connection anywhere in the welding

output circuit may limit the operation of the VRD.

This includes a good connection of the work clamp

to the job. The work clamp should be connected as

close as practical to where the welding will be per-

formed.

A. For New Electrodes

E6010 - Touch, Lift to Start the Arc

E7018, E7024 - Touch, Rock Back and Forth in

Joint, Lift .

Once the arc is started, normal welding technique

for the application is then used.

B. For Re-Striking Electrodes

Some electrodes form a cone at the end of the

electrode after the welding arc has been broken,

particularly iron powder and low hydrogen elec-

trodes. This cone will need to be broken off in order

to have the metal core of the electrode make con-

tact.

E6010 - Push, Twist in Joint, Lift

E7018, E7024 - P u s h , R o c k B a c k a n d F o r t h i n

Joint, Lift.

Once the arc is started, normal welding technique

for the application is then used.

For other electrodes the above techniques should

be tried first and varied as needed to suit operator

preference. The goal for successful starting is good

metal to metal contact.

For indicator light operation, see table B.1.

DOWNHILL PIPE Welding

This slope controlled setting is intended for "out-of-

position" and "down hill" pipe welding where the oper-

ator would like to control the current level by changing

the arc length.
