There are differences in the method of performing loudspeaker calibration on a standard
EXOTIK and an EXOTIK+DA:
Standard EXOTIK
You will need a test disc that contains a tone signal for each loudspeaker in your system.
Your specialist Linn retailer may be able to supply you with a suitable disc.
T
To
o p
pe
errffo
orrm
m s
sp
pe
ea
ak
ke
err c
ca
alliib
brra
attiio
on
n::
●
Add a Linn UNIDISK player (or other multi-channel disc playing source) to the
EXOTIK by following the source setup instructions in the next section.
●
Exit setup and change source to the UNIDISK/multi-channel disc playing source.
●
Re-enter setup and return to the SPEAKER CALIBRATION sub-menu.
●
Play the tracks on the test disc for speaker calibration while selecting the
appropriate loudspeakers from the EXOTIK’s menu.
●
If the tone signal coming from a particular loudspeaker is louder or quieter
than from the other loudspeakers, use the
/
keys on the handset to
trim the volume as required.
EXOTIK+DA
T
To
o p
pe
errffo
orrm
m s
sp
pe
ea
ak
ke
err c
ca
alliib
brra
attiio
on
n::
●
Select R
RE
EF
F.. C
CA
AL
LIIB
BR
RA
AT
TIIO
ON
N L
LE
EV
VE
EL
L. Adjust the reference calibration level so
that the signal you hear is at a comfortable listening level (or reaches a
preset level on an SPL meter).
●
Select N
NO
OIIS
SE
E. Choose either W
WH
HIIT
TE
E (equal energy per frequency, bright
sounding) or P
PIIN
NK
K (equal energy per octave, richer in lower frequencies than
White).
●
Select S
ST
TA
AR
RT
T. The signal will move round the loudspeakers in your system in
a clockwise direction and will be indicated on the display.
●
When the signal reaches a loudspeaker which is louder or quieter than the
other loudspeakers, use the
/
keys on the handset to trim the volume
as required. A few seconds after the
or
key has been released the
signal will continue its clockwise direction.
●
To stop loudspeaker calibration, press S
SE
ET
TU
UP
P on the handset or S
SE
EL
LE
EC
CT
T on
the front panel.
Range: --115
5 d
dB
B tto
o 115
5 d
dB
B (in 0.5 steps)
Default setting: 0
0 d
dB
B
Select S
SA
AV
VE
E to save your changes and return to the SPEAKER SETUP menu.
Select B
BA
AC
CK
K to return to the SPEAKER SETUP menu without saving changes.
Select E
EX
XIIT
T to leave setup (if changes have been made and SAVE has not been
selected, you will be prompted to save or not save the changes).
Select B
BA
AC
CK
K to return to the MAIN MENU.
Select E
EX
XIIT
T to leave Setup.
Source setup
Select the back panel input you wish to use with your source component, or select ADD
UNIDISK* if you are adding a Linn UNIDISK player as a source component.** You must
complete the source setup procedure for each source component you are connecting to
your EXOTIK.
Options: A
AN
NA
AL
LO
OG
G G
GR
RO
OU
UP
P,, A
AN
NA
AL
LO
OG
G 11 tto
o 6
6,, S
SP
PD
DIIF
F 11 tto
o 3
3*
*,, T
TO
OS
S ((T
TO
OS
SL
LIIN
NK
K)) 11 tto
o 3
3*
*,,
K
KN
NE
EK
KT
T,, A
AD
DD
D U
UN
NIID
DIIS
SK
K*
*
* EXOTIK+DA
**If you wish to connect a UNIDISK player to a standard EXOTIK use the ANALOG
GROUP inputs (for multi-channel systems) or a stereo input pair (for two-channel
systems).
