Chapter4
Advanced Configuration
2
Wreless-G ADSL Gateway wth SpeedBooster
DSL Connection
Status
The status of the DSL connection is displayed.
Downstream Rate
The download speed of traffic from
the Internet to the Gateway is displayed.
Upstream Rate
The upload speed of traffic from the
Gateway to the Internet is displayed. For ADSL connection,
the Upstream Rate is typically 25% of the Downstream
Rate.
NOTE:
The Downstream and Upstream Rates are
affected by distance from and configuration of
the DSL central office.
PVC Connection
Encapsulaton
The Encapsulation setting selected on
the Basic Setup screen is displayed.
DSL Modulaton Mode
The DSL Modulation Mode
selected on the Basic Setup screen is displayed.
Multplexng
The Multiplexing setting selected on the
Basic Setup screen is displayed.
Qos
The QoS method selected on the Basic Setup screen
is displayed.
PCR Rate
The PCR Rate value entered on the Basic Setup
screen is displayed.
SCR Rate
The SCR Rate value entered on the Basic Setup
screen is displayed.
Autodetect
The Autodetect setting selected on the Basic
Setup screen is displayed.
VPI
The VPI value entered on the Basic Setup screen is
displayed.
VCI
The VCI value entered on the Basic Setup screen is
displayed.
Enable
The number of Permanent Virtual Circuits (PVC)
is displayed.
PVC Status
The status of the PVC is displayed.
