LED Connection Module LAM48-1
The LED Connection Module LAM48-1 serves, as auxili-
ary module of a Remote Tableau Drive Unit PTU288-1,
to actuate up to 48 single LEDs, or relay outputs of a
Relay Module RL58-1 or RL58-2, in any combination. In
this way graphical orientation tableaus for signalling the
events of a fi re detection or extinguishing control panel
can be easily designed.
The events are assigned to the individual LEDs or relay
outputs by parameterising the remote tableau drive unit
by means of PARSOFT.
The signals are available on pin connectors, which are
prepared for connecting assembled LED cords. The
fi rst 16 outputs are routed in parallel to two fl at cable
connectors. Relay Modules RL58-1 or RL58-2 can be
directly connected to each of these two fl at cable con-
nectors. If more relay outputs are needed, 2-wire con-
nection cords can be used to actuate 2 further relays
each.
The componentry is delivered with the material needed
for mounting in the LST standard grid.
Specifi cations
Operating voltage 15 – 31VDC (supply through PTU288-1)
Current consumption at 24V typ. 3mA (quiescent)
max. 80mA (lamp test, 48 LEDs connected)
Ambient temperature -20°C to +60°C
Dimensions L × W × H 135 Ч 75 Ч 15 (mm)
Weight 62g
Order number 252013
Order name LED Connection Module LAM48-1
LEDs Assembled Green/Red/Amber
The package contains 10 light emitting diodes with as-
sembled connection cords, which serve to easily con-
nect and mount the LEDs on a synoptic remote tableau
in a time-saving way.
There is a luminous LED at one end of the cord. The
2-pin connector at the other end of the cord is connec-
ted to the pin connector of the LED Connection Module
LAM48-1.
The LED can be easily mounted by means of the sup-
plied black plastic clip.
Specifi cations
Operating voltage Supply through LED Connection Module LAM48-1
Length of LED cable 2m
LED ø 5mm
Drillled hole for LED clip ø 6.3 – 6.5mm
Thickness of front panel max. 2mm
LEDs Assembled Green
Order number 259011
Order name LED Assembled Green/10pcs. LED-GN/10
LEDs Assembled Red
Order number 259010
Order name LED Assembled Red/10pcs. LED-RT/10
LEDs Assembled Yellow
Order number 259012
Order name LED Assembled Yellow/10pcs. LED-GE/10
