Adjust and Programming
CONTRAST:
Adjusts the image brightness in relation to the background.
BRIGHTNESS:
Adjusts the overall image and background screen brightness.
H. POSITION:
To moves the picture image horizontally left or right.
H. SIZE:
To adjust the horizontal size of the image.
V. POSITION:
To moves the picture image vertically.
V. SIZE:
To adjust the vertical size of the image.
ROTATION: (optional)
Rotates the entire display clockwise or counter clockwise.
PINCUSHION:
To adjust the curvature of the sides
TRAPEZOID:
To adjust the bottom of the screen to be the same as the top.
PARALLELOGRAM:
To adjust the tilt of the side.
PIN. BALANCE:
To adjust the curvature of the side.
ADVANCED SELECT:
MOIRE ADJUSTMENT: The screen image may shake slightly while the moire cancellation
function is ON. It is normally OFF(H=0,V=0).
V. MOIRE:
To adjust the vertical moire of the image.
H. MOIRE:
To adjust the horizontal moire of the image.
CORNER: . (optional)
Use to adjust the alignment of top and bottom corner
TOP CORNER:
To adjust the top corner of the image.
BOTTOM CORNER:
To adjust the bottom corner of the image.
COLOR SELECT: This control adjusts the color temperature of the screen image.9300
°K and
6500
°K are preset by factory. You can not do adjustment.
9300
°K: Which is bluish white light.
6500
°K: Which is reddish white light.
USER: You can adjust the individual color gun intensity by yourself. Increase
or decrease red, green or blue depending upon which is selected.
12
