Chapter 4: Connecting the Router
Overview
Broadband Router with 2 Phone Ports
Chapter 4: Connecting the Router
Overview
To begin installation of the Router, you will connect the Router to your PCs, telephone(s) or fax machine(s), and
cable or DSL modem. The following connection diagram illustrates a basic network setup with one desktop PC
and telephone.
Figure 4-1: Router Connection Diagram
Telephone
Router
Cable/DSL Modem
Internet
PC
