Linksys BEFDSR41W - Manual (Page 14)

ADSL Gateway with Modem / Router / 4-Port Switch / Wireless-Ready
Chapter 5: Configuring the
Gateway
In this chapter, you will configure the Linksys ADSL Gateway to be able to
gain access to the Internet through your Internet Service Provider (ISP). You
will need the setup information provided by your ADSL ISP:
• Your ADSL line VPI and VCI
• Your ADSL encapsulation type and multiplexing
For PPPoA or PPPoE users, you also need these values from your ISP:
•
Your username and password
For RFC 1483 users, you may need these values from your ISP:
•
Your ADSL fixed Internet IP address
• Your Subnet Mask
• Your Default Gateway
• Your primary DNS IP address
The above information should have been provided by your ADSL ISP. If not, contact
your ISP and they will be able to supply you with the correct settings. The instructions
from your ISP tell you how to set up your PC for Internet access. Because you
are now using the Gateway to share Internet access among several computers,
you will use the setup information to configure the Gateway instead of your
PC. You only need to configure the Gateway once using the first computer you
set up.
19
Instant Broadband ™ Series
4. Select Internet Protocol (TCP/IP), and click the Properties button.
5. Select Obtain an IP address automatically. Once the new window
appears, click the OK button. Click the OK button again (or the Close but-
ton if any settings were changed) to complete the PC configuration.
6. Restart your computer.
Go to “Chapter 5: Configuring the Gateway.”
18
Figure 4-7
Figure 4-8
Configuring the Gateway
Figure 5-1
