EXTERNAL
EQ
UIPMENT
SETUP
20
DVD SETUP
EXTERNAL EQUIPMENT SETUP
When connecting Component cable
DIGITAL AUDIO
OUT
OPTICAL
A
V
OUT
A
V
IN 1
VIDEO
AUDIO
MONO
( )
S-VIDEO
COMPONENT IN
VIDEO
AUDIO
Y
L
R
P
B
P
R
AUDIO
( )
Component Input ports
To get better picture quality, connect a DVD player to the component input ports as shown below.
Component ports on the TV
Y
P
B
P
R
Video output ports
on DVD player
Y
Y
Y
Y
P
B
B-Y
Cb
Pb
P
R
R-Y
Cr
Pr
Connect the video outputs (Y, P
B
, P
R
) of the DVD to
the C
CO
OM
MP
PO
ON
NE
EN
NT
T IIN
N V
VIID
DE
EO
O1
1 jacks on the set.
Match the jack colors
(Y = green, P
B
= blue, and P
R
= red).
Connect the audio outputs of the DVD to the
C
CO
OM
MP
PO
ON
NE
EN
NT
T IIN
N A
AU
UD
DIIO
O1
1 jacks on the set.
1. How to connect
2. How to use
■
Turn on the DVD player, insert a DVD.
■
Select C
Co
om
mp
po
on
neen
ntt 1
1 input source by using the IIN
N P
P U
U T
T
button on the remote control.
■
If connected to C
CO
OM
MP
PO
ON
NE
EN
NT
T IIN
N 2
2 input, select
C
Co
om
mp
po
on
neen
ntt 2
2 input source.
■
Refer to the DVD player's manual for operating instructions.
