Monitor port – LevelOne GSW-2401TX User Manual
Page 31

25
Monitor Port
Entry:
Select “6” from Main Menu.
Purpose:
The switch supports port monitoring. This feature provides complete
network monitoring capability at 100 Mbit/s. A copy of egress (TX) data
and ingress (RX) data of the monitored port is sent to their respective
snooping ports.
Default:
Disable
Example : Monitored Port 1 , Monitoring for incoming packets port 2,
Monitoring for outgoing packets port 3.
1. type ‘M’ or ‘m’ to select Monitored Port
2. input ‘1’ and press ENTER
3. repeat step1 –2 for monitoring port incoming packets and outgoing
packets.
Select :>> 6
Monitor Port
[M] Monitored Port
[I] Monitoring Port for Incoming Packets
[O] Monitoring Port for Outgoing Packets
[D] Disable Port Monitor
[E] Exit
Select :>>
Select :>> m
Which port to be monitored (1 - 24)...
