5
LED Indicators
LED Indicators
LED Function Color Description
PWR Green Lit: Power on
SMART Green Lit: CPU installed
LINK/ACT Green/Yellow Green Lit: 100Mbps, indicates the adapter is
connected to hub and incoming
Yellow Flash: 10Mbps, traffic entering the port
10/100
L10/100/1000
Green Lit: indicate link status and traffic speed
(10/ L10 for 10M, 100/ L100 for 100M,
1000/ L1000 for 1000M)
TX/ RX Green Lit: indicate data traffic status
(TX for transmitting, RX for receiving)
FDX/ COL Green Lit: Full-Duplex
Flash: Half-Duplex/ Collision
Off: Half-duplex or not connected
Reset Switch
At the left side of front panel, the reset switch is designed for
reconfiguring the switch hub without turn off and on the power.
C
ONNECTING
T
HE
S
WITCH
Connecting End node or Hub or Switch
1. Place the Switch on a smooth surface or fasten the mounting
brackets with the provided screws in a standard 19” rack
2. Connect the DC jack of AC adapter to the DC inlet socket of
Switch and the other end into the local power source outlet
