General venting – Lochinvar Knight 80 - 285 User Manual
Page 13
Installation & Operation Manual
13
3
General venting
Figure 3-1 Two-Pipe Vertical Termination - See page
24 for more details
Figure 3-2 Two-Pipe Sidewall Termination - See
page 17 for more details
Figure 3-3 Concentric Vertical Termination - See
page 26 for more details
Figure 3-4 Concentric Sidewall Termination - See
page 21 for more details
Direct venting options
