Page 27: Design and operation, Figure 2-7. sample location in a cmc
DEFINITY AUDIX System Release 4.0
System Description Pocket Reference
585-300-214
Issue 1
May 1999
Design and Operation
2-11
Operating Requirements
Figure 2-7.
Sample Location in a CMC
scdxcm
c KLC
022299
MAJ
MIN
ON
OFF
AMBER
CARD
IN
USE
RED
EMER
XFER
ON
EM
XFR
AUTO
T
N
7
9
8
B
T
N
2
1
8
2
B
DEFINITY AUDIX
system
Empty space
Slot 6*
TN568
*The DEFINITY AUDIX system only
requires one slot in the CMC if it is
installed in slot 6
