DLP PROJECTOR
USER’S GUIDE
Thank you for purchasing the DLP Projector.
Please read this user’s guide to ensure correct use of the device. Save this user’s guide
for future reference.
OUTLINE
This DLP Projector can display various computer signals and NTSC/PAL/SECAM video
signals.
FEATURES
1. High Brightness
2. High Resolution
3. Compact Size, Feather Weight for Portability
4. Durable Magnesium Alloy Body
5. RGB input Terminal
6. One Touch Auto-Adjustment Function
7. Easy Keystone Adjustment
This manual is related to the following products:
Table of contents
Document Outline
- DLP Projector
- Thank you for purchasing the DLP Projector.
- Please read this user’s guide to ensure correct use of the device. Save this user’s guide for fut...
- This DLP Projector can display various computer signals and NTSC/PAL/SECAM video signals.
- Copyright
- Disclaimer
- Introduction
- 1. Read this user’s guide before you operate your projector and save it for future reference.
- 2. The lamp becomes extremely hot during operation. Allow the projector to cool for approximately...
- 3. Never replace the lamp assembly or any electronic components unless the projector is unplugged.
- 4. To reduce the risk of electric shock, do not disassemble this appliance. Take it to a qualifie...
- 5. Do not place this product on an unstable cart, stand, or table. The product may fall, sustaini...
- 6. Do not touch the top cover when the projector is under operation.
- 7. The projector must be packaged into a carry bag while moving to another place for operation.
- The Projector is shipped with the cables required for connection to standard PC or laptop compute...
- The indicator shows green for a normal state. When the projector is operated improperly, it shows...
- Press the POWER key to turn the projector on or off.
- Automatically determines the best picture settings for current received signals. (PC Mode Only)
- Selects signal sources from among PC, Video, S-Video and YPBPR.
- Selects to display an entirely blue, black, green or LG logo screen.
- The projector is equipped with 1 quick-release adjuster foot. Push the button to adjust its tilt ...
- Note: The adjuster can only bear the weight of the projector itself . Please do not place any add...
- The projector integrates high-performance optical engine projection and a user- friendly design t...
- The projector offers the following features:
- Note: The brightness of the projected image will vary depending on the ambient lighting condition...
- The remote control sensors are located in the front/ back of the projector.
- Press and open the battery compartment lid in the direction.
- Installation
- Place the projector at the required distance from the screen according to the desired picture siz...
- L Projection Distance
- HDTV description
- The projector is capable of displaying various High Definition TV display modes. Some of these so...
- Most of these sources will provide an analog component video output, a standard VGA output, or a ...
- The projector is capable of accepting HDTV data through a YPBPR connector. Use a HDTV cable that ...
- The following standards are supported in the HDTV function:
- Please refer to "Menu System" on page 14 for information on the HDTV (YPBPR) OSD selections.
- Connecting to Various Equipment
- Operation
- 1. Plug the power cord into a wall socket. Open the front Door to Power ON.
- 2. When plugging-in, the ORANGE Leds light. Press the Power button to turn on the projector. Then...
- 3. Switch on all connected equipment.
- Keystoning refers to the situation where the projected image is noticeably wider at either the to...
- In some cases, you may need to optimize the picture quality. To do this, press the AUTO key on th...
- *This function is available only in PC mode.
- When several input sources are available, press the SOURCE key to make a selection from the contr...
- Press Menu for the main menu, and then press Joystick to select a sub-menu. Press ENTER again to ...
- Default
- Projects images when the projector is 180 degrees horizontally rotated.
- Default
- Projects images when the projector is 180 degrees vertically rotated.
- This sub-menu only works in PC mode.
- * After the projector is turned off, there is a 90-second cooling period before the projector can...
- Maintenance
- Troubleshooting
- Specifications
- Technical Specifications
- Product name
- Personal Projector
- Model name
- RD-JT30 1024X768 XGA
- RD-JT31 800X600 SVGA
- Display system
- 1-CHIP DMD
- Lens F/Number
- F/2.4
- Lamp
- 150W NSH lamp
- Electrical
- Power supply
- AC100 ~ 240V, 3A, 50/60 Hz (Automatic)
- Power consumption
- 250 W (Max)
- Dimensions
- 248 mm (W) x 59 mm (H) x 170 mm (D)
- Operating temperature range
- 5˚C ~ 35˚C
- Weight
- 3 lbs (1.7 Kg)
- Computer input
- RGB input (HDTV: YPBPR)
- D-sub 15-pin (female)
- Video signal input
- S-VIDEO
- Mini DIN 4-pin port x1
- VIDEO
- RCA jack x1
- Output
- USB mouse connector
- A/B series x1
- Resolution
- H Sync (kHz)
- V Sync (Hz)
- Remark
- 640x350
- 31.5
- 70.1
- 640x400
- 37.9
- 85.1
- VESA
- 720x400
- 31.5
- 70.0
- 720x400
- 37.9
- 85.1
- VESA
- 640x480
- 31.5
- 60.0
- VESA
- 640x480
- 35.0
- 66.7
- Macintosh
- 640x480
- 37.9
- 72.8
- VESA
- 640x480
- 43.3
- 85.0
- VESA
- 800x600
- 35.2
- 56.3
- VESA
- 800x600
- 37.9
- 60.3
- VESA
- 800x600
- 48.1
- 72.2
- VESA
- 800x600
- 46.9
- 75.0
- VESA
- 800x600
- 53.7
- 85.1
- VESA
- 832x624
- 49.7
- 74.5
- Macintosh
- 1024x768
- 48.4
- 60.0
- VESA
- 1024x768
- 56.5
- 70.1
- VESA
- 1024x768
- 60.0
- 75.0
- VESA
- 1024x768
- 68.7
- 85.0
- VESA
- 1280x1024
- 64.0
- 60.0
- VESA
- Technical Specifications
- Dimensions
