LCD TV Models
Connect the cables as necessary.
To connect additional equipment, see the
EXTERNAL EQUIPMENT SETUP section.
Install the CABLE MANAGEMENT CLIP as
shown.
CABLE MANAGEMENT CLIP
1
2
Align the hole with the tab on the C CA AB BLLEE
M MA AN NA AG GEEM MEEN NT T C CLLIIPP.
Turn the C CA AB BLLEE M MA AN NA AG GEEM MEEN NT T C CLLIIPP as
shown.
Note: This cable management clip can be bro-
ken by excessive pressure.
Connect the cables as necessary.
To connect additional equipment, see the
EXTERNAL EQUIPMENT SETUP section.
1
2
Put the cables inside the CABLE MANAGEMENT
CLIP and snap it closed. 3
32/37/42/47/52LG60 32/37/42LG30, 37/42/47/52LG50,
32/42/47/52LG70
