REPLACEMENT PARTS
ITEM
NO.
DESCRIPTION MPE-33R
CAT. NO. QTY
1 Bulb Kit, (10 Each 35w Halogen) H1623 1
2 Side Frames, 1 Left And 1 Right H1942 1
3 Circuit Board H1625 1
4 Nailing Flange Kit, (4 Each) H1626 1
5 Glass Brick Panel H1943 1
6 Glass Retaining Bracket Kit: Left, Right, & Top H1628 1
7 Grate Assembly H1944 1
8a Blower, Heating Element & Access Panel Assembly H1630 1
8b Fuse Plate Assembly (5 each) H5043 1
9 Flame Cylinder Assembly H1631 1
10 Flame Motor H1632 1
11 Lennox Logo Kit (1 Each) 12L15 1
12 Log / Ember Bed Assembly H1945 1
13 Panel, Bottom, Front H1946 1
14 Panel, Flame Cover H1947 1
15 Panel, Louver, Upper Front H1948 1
16 Panel, Upper Frame Top H1949 1
17 Electrical Outlet Cover Plate H1639 1
18 Screen Set, Pull H1640 1
19 Switch, Toggle (1 Each) H1641 1
20 Transformer Assembly H1642 1
21 Wire Harness H1643 1
22 Remote Control, Electric H1644 1
23 Power Cord (110 V only) H1645 1
Note: If touch-up paint is needed, use Rust-oleum ® , Painter’s Touch, Flat Black (part number 1976) available at most stores which sell
aerosol touch-up paint.
