INSTALLATION INSTRUCTIONS FOR LEg LEVELINg pAdS FOR USE WITH BELLA™ pELLET
STOVES ANd gRANdVIEW™ WOOd STOVES WITH COASTAL OR LAkEVIEW LEgS
LEg LEVELINg pAdS kIT
BELLA™, gRANdVIEW™
Figure 1
Cat. # Model description
H7638 BELLA-LLk Leg Leveling pads kit
kIT CONTENTS (See Figure 1)
4 ea. Leg Leveling Pads
1 ea. Instruction Sheet
INSTALLATION INSTRUCTIONS (STANdARd INSTALLATION)
Step 1. Using an escalera or other heavy lifting device, secure and lift the
stove to expose the bottom of the cast legs.
Step 2. Screw in leg leveling pads to all four (4) legs (Figure 1).
Printed in U.S.A. © 2008 Lennox Hearth Products
p/N 506033-21 REV. A 09/2011
Lennox Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and the discontinuance of colors, styles and products. Consult
your local distributor for fireplace code information.
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Lennox Hearth products
1508 Elm Hill pike, Suite 108 • Nashville, TN 37210
Bella pellet Stove
grandview™ Wood Stove with Coastal or Lakeview Legs
Coastal Leg Lakeview Leg
TOOLS NEEdEd
Escalera or other Heavy Lifting Device
gENERAL INFORMATION
If you encounter any problems, need clarification of these instructions or are
not qualified to properly install this kit, contact you local distributor or dealer.
Read this instruction sheet in its entirety before beginning the installation.
ALL WARNINgS ANd pRECAUTIONS IN THE INSTALLATION ANd Op-
ERATION MANUAL pROVIdEd WITH THE AppLIANCE AppLY TO THESE
INSTRUCTIONS.
TURN OFF THE STOVE ANd ALLOW IT TO COMpLETELY COOL BEFORE
pROCEEdINg.
