Clear Concept

The BCnet Sectional Control Panel/Extension

BCE216-3LG extends a BCnet sectional control panel

BC216-2 or BC216-3, respectively, by two ADM loops.

It provides the following features:

• Detectors and modules in ADM loop technology can

be connected to each Loop Interface LIF64-1. Depen-

ding on the parameterisation, either the Apollo/Disco-

very protocol or the System Sensor/200 protocol is

used to achieve bi-directional data transfer.

• Logical combinations of detectors and detector zo-

nes for the activation of external controls and alar-

ming devices facilitate maximum ﬂ exibility. Thus, no

additional expenses arise for external relays, logic

gates or timers. Thanks to the wide range of parame-

terisation possibilities, individual requirements even

under the most difﬁ cult ambient conditions can be

combined into a reasonable ﬁ re protection strategy.

• By integrating input and output modules on any positi-

on in the loop you can realize enablements or disable-

ments as well as control tasks in your system without

having to care for additional wires.

• The free combination of detectors and modules into

logic sectors allows for the joint operation of deﬁ ned

parts of the system even beyond the limits of loops

or sectional control panels.

• The use of unshielded loop cables allows for cost-

saving and uncomplicated installation as well as for

the possibility of reusing the existing cabling.

• At a possible breakdown of the central processing

unit which is integrated on the extension, the diver-

siﬁ ed redundancy concept ensures secure alarm re-

cognition.

• The parameter data can be created by means of the

PC software PARSOFT and loaded into the control pa-

nel in a comfortable way. Thus, a quick and efﬁ cient

transfer of the system conﬁ guration into the control

panel is guaranteed.

• AUTO setup facilitates parameterisation when the

control panel is commissioned or expanded and thus

helps to save time.

The BCnet Sectional Control Panel/Extension

BCE216-3LG is suitable for later installation in the wall

mount cabinet.

Owing to the compact design, a maximum of four loops

can be centralized in one single place. The required bat-

teries are accommodated in the wall mount cabinet or

in an external auxiliary case. Series BC216 thus stands

for modularity and easy expansion.

This product complies with all relevant standards of

EN 54 and is VdS-certiﬁ ed. In addition, the product also

holds several country-speciﬁ c approvals and certiﬁ ca-

tes. LST‘s high quality level is secured by a permanent-

ly monitored quality management system certiﬁ ed by

ISO 9001.
