Page 12
6
Chapter 3: Getting to Know and Using the Wireless-G Network Adapter with Wi-Fi Finder
The Front Panel
Wireless-G USB Network Adapter with Wi-Fi Finder
Chapter 3: Getting to Know and Using the Wireless-G
Network Adapter with Wi-Fi Finder
The Front Panel
The Network Adapter's LEDs and Wi-Fi Finder LCD screen are located on the Front Panel.
LEDs
Power
Green. The Power LED lights up when the Adapter is powered on.
Link
Green. The Link LED lights up when there is wireless activity.
Figure 3-1: Front Panel
Power LED
Link LED
Wi-Fi Finder’s
Wireless
Network Screen
USB
Connector
