DATE: 2002. 12. 10.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C904 0CZZTCB003A BULK 7.5 CS E 222M 10.5 250V T
C905 0CZZTCB003A BULK 7.5 CS E 222M 10.5 250V T
C905 0CZZTCB003A BULK 7.5 CS E 222M 10.5 250V T
C906 0CZZTCB003D BULK 7.5 CS E 102M 8.0 250V TD
C907 0CZZTCB003C BULK 7.5 CS E 472M 14.5 250V T
C908 0CEZTBU002D 180UF 25.4*35 SMH/HC 400V M VN
C909 0CK10301510 0.01M 1KV K B S
C910 0CK27101515 270P 1KV K B TS
C911 0CE475CK638 4.7UF SHL,SD 50V M FM5 TP 5
C913 0CE476CK638 47UF SHL,SD 50V M FM5 TP 5
C914 0CZZTFT001P ECQB1H153JM3 153J 50V TP5.0 MA
C915 0CK6810K515 680P 50V K B TS
C917 0CK1020K515 1000PF 50V K B TR
C918 0CN1040K949 0.1M 50V Z F TA52
C941 0CE108CD618 1000UF SHL 10V M FL TP5
C942 0CE107CF638 100UF SHL,SD 16V M FM5 TP 5
C943 0CK56101515 560P 1KV K B TS
C944 0CZZTCB003C BULK 7.5 CS E 472M 14.5 250V T
C946 0CK1010W515 100P 500V K B TS
C951 0CE108CF630 1000UF SHL 16V M FM5 BULK
C952 0CE227CF638 220UF SHL,SD 16V M FM5 TP 5
C953 0CE107CF638 100UF SHL,SD 16V M FM5 TP 5
C954 0CE108CF630 1000UF SHL 16V M FM5 BULK
C971 0CE476CN618 47UF SHL 100V M FL TP5
C999 0CE227CL630 220U SHL 63V M FM5
D201 0DLGP0010AB XIAMEN G&P GP32052ME/512-ZY-1
D301 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D302 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D303 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D304 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D305 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D306 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D307 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D308 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D309 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D310 0DS124409AA 1SS244 TP ROHM KOREA
D311 0DS124409AA 1SS244 TP ROHM KOREA
D312 0DS124409AA 1SS244 TP ROHM KOREA
D313 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D399 0DR140059DA 1N4005TB52 TP LITEON DO41 600V
D402 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D404 971-0016 TIN HDC 0.60H
D512 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D602 0DRGF00069A SB140 GULF TP DO41 40V 1A 40A
D610 0DR100009CA RGP10G TP GULF SEMICONDUCTOR L
D610 0DR100009CA RGP10G TP GULF SEMICONDUCTOR L
D701 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D702 0DS124409AA 1SS244 TP ROHM KOREA
D703 0DRTW00050A MUR460L-1121 TIWAN SEMI BK DO2
D704 0DR150001AA DTV1500MFP ST SGS-THOMSON TO22
D705 0DRGF00069A SB140 GULF TP DO41 40V 1A 40A
D706 0DRGS00380B GRD07-17L-5705 GENERAL SEMICON
D709 971-0016 TIN HDC 0.60H
D710 0DR400409AB UF4004 TP G.I DO204AL 400V 1A
D711 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D712 0DR100009CA RGP10G TP GULF SEMICONDUCTOR L
D712 0DR100009CA RGP10G TP GULF SEMICONDUCTOR L
D713 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D714 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
DATE: 2002. 12. 10.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D715 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D716 0DR140059DA 1N4005TB52 TP LITEON DO41 600V
D717 0DR140059DA 1N4005TB52 TP LITEON DO41 600V
D718 0DR140059DA 1N4005TB52 TP LITEON DO41 600V
D719 0DR100009DA RGP10J TP GULF SEMICONDUCTOR L
D720 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D721 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D723 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D724 0DR140059DA 1N4005TB52 TP LITEON DO41 600V
D767 0DR100009DA RGP10J TP GULF SEMICONDUCTOR L
D768 971-0016 TIN HDC 0.60H
D801 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D802 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D803 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D900 0DRTW00071A TS4B05G-1021 TIWAN SEMI ST NON
D902 0DR153979AA 1N5397GP TP G.I DO201AD 600V 1
D904 0DR100009CA RGP10G TP GULF SEMICONDUCTOR L
D904 0DR100009CA RGP10G TP GULF SEMICONDUCTOR L
D905 0DD400709CB UF4007 TP G.I DO204AL 1000V 1
D906 0DR100009CA RGP10G TP GULF SEMICONDUCTOR L
D906 0DR100009CA RGP10G TP GULF SEMICONDUCTOR L
D908 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D910 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D911 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D941 0DR100009LA UG1D TP G.I DO204AL 200V 1A 40
D942 0DR400409AB UF4004 TP G.I DO204AL 400V 1A
D951 0DRTW00044B UG2DL-1021 TIWAN SEMI BK DO15
D952 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D961 0DRTW00060A SF38GL-1121 TIWAN SEMI BK DO20
D971 0DR100009DA RGP10J TP GULF SEMICONDUCTOR L
ZD402 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD403 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD404 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD405 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD407 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD408 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD409 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD410 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD701 0DZ120009BF GDZJ12B TP GRANDE DO34 0.5W 12
ZD702 971-0016 TIN HDC 0.60H
ZD902 0DZ510009BE GDZ5.1B TP GRANDE DO34 500MW 5
IC301 0IPRPWL001A 6805-N160WT-87A WELTREND 16, P
IC302 0IPRPSG014A STV9211 SGS-THOMSON 20P,DIP ST
IC303 0IPRPSG004B STV9556 SGS-THOMSON 11P,CLIPWA
IC401 0IZZTSZ223A “SS 42PIN SDIP ST OTP 17”” H4 ST”
IC402 0ISG240860A M24C08-BN6 8DIP BK 8K SERIAL I
IC601 0IPRPSG016A STV9302A SGS-THOMSON TO220,7P
IC701 0IPRPSG017A STV6888 SGS-THOMSON 32P,SDIP S
IC901 0ISS384200A KA3842B (PWM)
L301 0LA0560K119 0.56UH K 2.3*3.4 TP
L302 0LA0560K119 0.56UH K 2.3*3.4 TP
L303 0LA0560K119 0.56UH K 2.3*3.4 TP
L304 0LA1000K119 100UH K 2.3*3.4 TP
L702 6140TBZ025C DR14*20 150UH 0.12*25MM 51T H-
L703 6140TYZ010G LX31 GET DR14*15-C5.2,16.5T,4.
L705 6140TBZ026C DR15*18-C9.8 100UH 0.1*30MM 40
L901 6200TZZ004A SQE2626 NAMYANG BK L/FILTER 15
- 25 -
DIODEs
ICs
COILs & COREs
