TROUBLESHOOTING GUIDE
- 12 -
1. NO POWER
NO POWER
(POWER INDICATOR OFF)
TROUBLE IN
D900
TROUBLE IN FUSE
(F901)
TROUBLE IN
Q901
TROUBLE IN
D941, D942, D951,
D961, D971
TROUBLE IN
Q903, Q952,
Q951, Q942, Q941
CHECK
FUSE OK?
CHECK
C908 VOLTAGE?
(AC120V: 160VDC,
AC220V: 304VDC)
NO
YES
YES
YES
YES
NO
NO
NO
CHECK
Q901 PIN 6
WAVEFORM
?
CHECK
D941, D942,
D951, D961, D971
VOLTAGE?
