1. PICTURE TUBE

Size

: 17 inch

DefIection Angle

: 90°

Neck Diameter

: 29.1 mm

Dot Pitch

: 0.27 mm

Face Treatment

: W-ARASC (Anti-Reflection and

Anti-Static Coating)

Low Radiation

: MPR II, TCO 99

2. SIGNAL

2-1. Horizontal & Vertical Sync

1) Input Voltage Level : Low=0~1.2V, High=2.5~5.5V
2) Sync Polarity

: Positive or Negative

2-2. Video Input Signal

1) Voltage Level

: 0 ~ 0.7 Vp-p

a) Color 0, 0

: 0 Vp-p

b) Color 7, 0

: 0.467 Vp-p

c) Color 15, 0

: 0.7 Vp-p

2) Input Impedance

: 75

3) Video Color

: R, G, B Analog

4) Signal Format

: Refer to the Timing Chart

2-3. Signal Connector

3 row 15-pin Connector (Attached)

2-4. Scanning Frequency

Horizontal

: 30 ~ 71 kHz

Vertical

: 50 ~ 160 Hz

3. POWER SUPPLY

3-1. Power Range

AC 100~220V, 60Hz, 2.0A Max.

3-2. Power Consumption

4. DISPLAY AREA

4-1. Active Video Area :

• Max Image Size - 326.7 x 245.5 mm (12.86" x 9.67")
• Preset Image Size - 310 x 230 mm (12.20" x 9.06")

4-2. Display Color

: Full Colors

4-3. Display Resolution

: 1280 x 1024 / 60Hz(Max)

(Non-Interlace)

4-4. Video Bandwidth

: 110 MHz

5. ENVIRONMENT

5-1. Operating Temperature: 0°C ~ 40°C

(Ambient)

5-2. Relative Humidity

: 10%~ 90%

(Non-condensing)

5-3. Altitude

: 5,000 m

6. DIMENSIONS (with TILT/SWIVEL)

Width

: 400.0 mm (15.74 inch)

Depth

: 430.0 mm (16.92 inch)

Height

: 410.0 mm (16.14 inch)

7. WEIGHT (with TILT/SWIVEL)

Net Weight

: 14.4 kg (31.75 lbs.)

Gross Weight

: 16.6 kg (36.60 lbs.)

CONTENTS

- 2 -

SPECIFICATIONS ................................................... 2

SAFETY PRECAUTIONS ........................................ 3

TIMING CHART ....................................................... 4

OPERATING INSTRUCTIONS ................................ 5

WIRING DIAGRAM ................................................. 6

DISASSEMBLY ....................................................... 7

BLOCK DIAGRAM ................................................... 8

DESCRIPTION OF BLOCK DIAGRAM................... ..9
ADJUSTMENT ...................................................... 10
TROUBLESHOOTING GUIDE .............................. 12
EXPLODED VIEW................................................... 22
REPLACEMENT PARTS LIST ............................... 24
PIN CONFIGURATION........................................... 29
SCHEMATIC DIAGRAM ......................................... 34
PRINTED CIRCUIT BOARD................................... 36

SPECIFICATIONS

MODE

MAX

NORMAL (ON)

STAND-BY

SUSPEND

OFF

POWER CONSUMPTION

85 W

73 W

less than 15 W

less than 15 W

less than 5 W

LED COLOR

GREEN

GREEN

AMBER

AMBER
