Page 19: Channel selection with

19
TV VIEWING
TV V
TV V
iewing
iewing
Channel Selection
Channel Selection
You can select a channel as shown below.
Number and – (dash) buttons
Use Number (0-9) and – (dash) buttons to select a
channel directly.
- For example, to select digital channel number
27-1, press “2”, “7”, “-”, “1” and press ENTER ( )
- For example, to select analog channel number
27, press “2”, “7” and press ENTER ( ).
FAV. CH +/- button
Press FAV +/– to scroll through your favorite
channels.
To set a favorite channel, use [Channel Edit] option in
the Setup menu. (See page 50-51.)
CH/TRK +/– buttons
Use CH/TRK +/– on the Remote Control or CH v/V
on the front panel to cycle the recorder through the
channels in memory.
Channel Selection with
Channel Selection with
Channel List menu
Channel List menu
Displaying Channel List and Changing
Channel
1.
Press HOME ( ) and the Home menu appears.
2.
Select [TV] > [Channel List] and press ENTER
( ). The channel list menu will appear.
3.
Select your desired channel using the v / V and
press ENTER ( ) to change the channel.
Switching Channel List
Four types of channel lists are provided for easy and
quick channel searching. You can switch the channel
lists to TV (CATV), DTV (CADTV), Favorite or ALL.
1.
Press v to move the highlight position to top of
the channel list.
2.
Press b / B to select a [TV (CATV)], [DTV
(CADTV)], [Favorite] or [ALL].
Selected channel list appears.
TV (CATV): Shows all analog TV channels.
DTV (CADTV): Shows all digital TV channels.\
Favorite: Shows favorite channels.
(favorite channel shows
icon)
ALL: Shows all analog and digital channels.
FAV
Note
Note
*
Number (0-9) and
– DASH buttons
FAV. CH +/- and
CH/TRK +/– buttons
