Parameter table
MENU
SUB ITEM
DESCRIPTION
SEE
PAGE
USER ACCESS
INSTALLER ACCESS
DISPLAY
MODIFY
DISPLAY
MODIFY
A
1
Heater Model
11
Yes
No
Yes
No
2
User Code
11
Yes
Yes
Yes
Yes
3
Date and Time
11
Yes
Yes
Yes
Yes
4
Software Version
11
Yes
No
Yes
No
5
Temperature Units
11
Yes
Yes
Yes
Yes
6
Night Setback Temperature
11
Yes
Yes
Yes
Yes
7
Night Setback Times
11
Yes
Yes
Yes
Yes
GENERAL
B
1
SH Set Point User
11
Yes
Yes
Yes
Yes
C
1
Hours Running SH
11
Yes
No
Yes
No
2
Hours Running DHW
11
Yes
No
Yes
No
3
Ignition Attempts
11
Yes
No
Yes
No
4
Show Last 10 Errors
11
Yes
No
Yes
No
DATA
E
1
DHW Tank Set Point
12
Yes
Yes
Yes
Yes
2
DHW Boiler Set Point
12
Yes
Yes
Yes
Yes
3
SH/DHW Switching Time
12
Yes
Yes
Yes
Yes
F
5
Outdoor Air Shutdown
12
Yes
Yes
Yes
Yes
6
Outdoor Air Shutdown Differential
12
Yes
Yes
Yes
Yes
8
Boost Temperature
12
Yes
Yes
Yes
Yes
9
Boost Time
12
Yes
Yes
Yes
Yes
TEMPERATURE
SETTING
LOGGING
DHW
SETTINGS
OUTDOOR
AIR
RESET
Table 3A_This table lists SMART SYSTEM control module parameters and where to access them
